Mechanical Pressure Switches

PS10

Piston Pressure Switch

PS10 Piston Pressure Switch with catalog-listed configuration options.

PS10 Piston Pressure Switch product photograph
RANGEAdjustment range: 10~320 bar, or custom
OUTPUTSPDT changeover contacts
MATERIALPTFE piston seal
PROTECTIONIP65 to DIN EN 60529

Product overview

Application-focused measurement and switching.

The current catalog lists selection data for the PS10 Piston Pressure Switch. Confirm the exact ordered configuration and controlled rating before use.

Configuration note

Ratings, materials, interfaces, and approvals can vary by ordered configuration. CASCED INC confirms the controlled specification before order acceptance.

Key features

  • Electrical rating: 250 V / 6 A
  • Operating media: Self-lubricating fluids (e.g. hydraulic oil), neutral fluids/gases
  • Maximum system pressure: 350 bar, or custom

Technical specifications

Key data for product selection.

Electrical rating
250 V / 6 A
Operating media
Self-lubricating fluids (e.g. hydraulic oil), neutral fluids/gases
Maximum system pressure
350 bar, or custom
Repeatability
At room temperature, max. ±2% FS
Hysteresis
Reference: 5 bar + (5~10)% of set point; not adjustable
Temperature range
-40°C~+100°C

Further dimensions, connection diagrams and ordering details are in the current catalog, full pages 44–45. Open the matching English PDF pages. Published values and options are configuration dependent. Confirm the selected configuration before use.

Downloads

Technical documentation

View in your browser or download a copy for engineering and sourcing review.

Typical applications

Engineered for real industrial systems.

01Application review based on supplied operating conditions
02OEM and industrial equipment projects
