Mechanical Pressure Switches

PSKDF26

Pressure Switch

PSKDF26 Pressure Switch with catalog-listed configuration options.

PSKDF26 Pressure Switch product photograph
OUTPUTBlade contacts; SPST normally open or normally closed options
MATERIALStandard NBR diaphragm; optional Viton, EPDM or HNBR; zinc-plated steel housing with stainless-steel option
PROTECTIONIP67

Product overview

Application-focused measurement and switching.

The current catalog lists selection data for the PSKDF26 Pressure Switch. Confirm the exact ordered configuration and controlled rating before use.

Configuration note

Ratings, materials, interfaces, and approvals can vary by ordered configuration. CASCED INC confirms the controlled specification before order acceptance.

Key features

  • Electrical connector: Integrated Deutsch DT04-2P receptacle; mating DT06-2S plug
  • Temperature range: -20°F~180°F (-29°C~82°C), NBR
  • Maximum overpressure: 9000 PSI (600 BAR)

Technical specifications

Key data for product selection.

Electrical connector
Integrated Deutsch DT04-2P receptacle; mating DT06-2S plug
Temperature range
-20°F~180°F (-29°C~82°C), NBR
Maximum overpressure
9000 PSI (600 BAR)
Mechanical life
1 million cycles at 1000 PSI (69 BAR)
Contact material
Silver-nickel alloy; gold contacts optional

Further dimensions, connection diagrams and ordering details are in the current catalog, full pages 56–57. Open the matching English PDF pages. Published values and options are configuration dependent. Confirm the selected configuration before use.

Downloads

Technical documentation

View in your browser or download a copy for engineering and sourcing review.

Typical applications

Engineered for real industrial systems.

01Application review based on supplied operating conditions
02OEM and industrial equipment projects

Contact technical sales

Share your operating conditions, interfaces, quantity, and documentation requirements.
