Mechanical Pressure Switches

PSLF29

Pressure Switch

PSLF29 Pressure Switch with catalog-listed configuration options.

PSLF29 Pressure Switch product photograph
OUTPUTSnap-disc switch with automatic reset
MATERIALStandard stainless-steel diaphragm; brass housing
PROTECTIONExposed terminals: IP00

Product overview

Application-focused measurement and switching.

The current catalog lists selection data for the PSLF29 Pressure Switch. Confirm the exact ordered configuration and controlled rating before use.

Configuration note

Ratings, materials, interfaces, and approvals can vary by ordered configuration. CASCED INC confirms the controlled specification before order acceptance.

Key features

  • Electrical rating: 2 A (12/24 VDC) or 120/240 VAC, 375 VA
  • Temperature range: -40°F~180°F (-40°C~82°C)
  • Mechanical life: 100,000 cycles

Technical specifications

Key data for product selection.

Electrical rating
2 A (12/24 VDC) or 120/240 VAC, 375 VA
Temperature range
-40°F~180°F (-40°C~82°C)
Mechanical life
100,000 cycles
Proof pressure by set point
Set point up to 145 PSI (10 BAR): 500 psi (35 BAR); 146 PSI (10.1 BAR)~290 PSI (20 BAR): 770 PSI (55 BAR); 291 PSI (20.1 BAR)~630 PSI (45 BAR): 1200 PSI (85 BAR)

Further dimensions, connection diagrams and ordering details are in the current catalog, full pages 62–63. Open the matching English PDF pages. Published values and options are configuration dependent. Confirm the selected configuration before use.

Downloads

Technical documentation

View in your browser or download a copy for engineering and sourcing review.

Typical applications

Engineered for real industrial systems.

01Application review based on supplied operating conditions
02OEM and industrial equipment projects
