Mechanical Pressure Switches

PSPAL28 / PSPFL28 / PSPFLH28

Pressure Switch

PSPAL28 / PSPFL28 / PSPFLH28 Pressure Switch with catalog-listed configuration options.

PSPAL28 / PSPFL28 / PSPFLH28 Pressure Switch product photograph
OUTPUTBlade contacts; SPST or SPDT options
MATERIALStandard polyimide-film diaphragm; EPDM option required for water media; brass and glass-fiber-reinforced polyester housing, stainless-steel option
PROTECTIONExposed terminals: IP00; FL lead option with IP68 protective cap

Product overview

Application-focused measurement and switching.

The current catalog lists selection data for the PSPAL28 / PSPFL28 / PSPFLH28 Pressure Switch. Confirm the exact ordered configuration and controlled rating before use.

Configuration note

Ratings, materials, interfaces, and approvals can vary by ordered configuration. CASCED INC confirms the controlled specification before order acceptance.

Key features

  • Temperature range: -40°F~248°F (-40°C~120°C), polyimide diaphragm
  • Maximum overpressure: Models 1A~5A: 150 PSI (10.35 BAR); 6A~8A: 250 PSI (17 BAR); 1H~5H: 500 PSI (34 BAR)
  • Mechanical life: 1 million cycles at 75 PSI (5.2 BAR)

Technical specifications

Key data for product selection.

Temperature range
-40°F~248°F (-40°C~120°C), polyimide diaphragm
Maximum overpressure
Models 1A~5A: 150 PSI (10.35 BAR); 6A~8A: 250 PSI (17 BAR); 1H~5H: 500 PSI (34 BAR)
Mechanical life
1 million cycles at 75 PSI (5.2 BAR)
Contact material
Gold-plated silver alloy

Further dimensions, connection diagrams and ordering details are in the current catalog, full pages 60–61. Open the matching English PDF pages. Published values and options are configuration dependent. Confirm the selected configuration before use.
