Pressure Transmitters

5425 Series

Miniature Pressure Transmitter

5425 Series Miniature Pressure Transmitter with catalog-listed configuration options.

5425 Series Miniature Pressure Transmitter product photograph
RANGEListed standard pressure ranges: 10, 16, 30, 50, 100, 200, 250, 400, 500, 700 bar
OUTPUT4~20 mA; 1~5 V; 0~4.5 V; 0~5 V; 0~10 V options
MATERIALStainless-steel mechanical parts; FKM seals or customer-specified seal material
PROTECTIONIP67 (M12×1 connector)

Product overview

Application-focused measurement and switching.

The current catalog lists selection data for the 5425 Series Miniature Pressure Transmitter. Confirm the exact ordered configuration and controlled rating before use.

Configuration note

Ratings, materials, interfaces, and approvals can vary by ordered configuration. CASCED INC confirms the controlled specification before order acceptance.

Key features

  • Pressure reference: Gauge or absolute pressure
  • Process connection: G1/4A, or custom
  • Measured media: Gases and liquids; media must not corrode 304 or 316 stainless steel

Technical specifications

Key data for product selection.

Pressure reference
Gauge or absolute pressure
Process connection
G1/4A, or custom
Measured media
Gases and liquids; media must not corrode 304 or 316 stainless steel
Overall accuracy options
±0.5% FS; ±0.25% FS; ±0.1% FS
Operating temperature
-40°C~+125°C
Sensor
Silicon pressure-sensing element with stainless-steel isolation diaphragm

Further dimensions, connection diagrams and ordering details are in the current catalog, full pages 15–17. Open the matching English PDF pages. Published values and options are configuration dependent. Confirm the selected configuration before use.
